ADVANCED CNC MACHINING TECHNICIAN: GENERAL INFORMATION
Click to see more images
| Name of the Trade | ADVANCED CNC MACHINING TECHNICIAN (Engineering Trade) |
|---|---|
| Trade Code | DGT/2027 |
| NCO - 2015 | 7223.5001, 7223.5002, 7223.5003, 7223.5004, 7223.6001, 7223.6002, 7223.6003, 7223.9900, 7223.0502. |
| NOS Covered | CSC/N1335,CSC/N0116,CSC/N0115 ,CSC/N9408, CSC/N9401,CSC/N0120 ,CSC/N0123 ,CSC/N9402, ISC/N9416,ISC/N9417 ,SC/N9418 ,ISC/N9419 |
| NSQF Level | Level – 4 |
| Duration of Craftsmen Training | Two years (2400 hours + 300 hours OJT/Group Project) |
| Entry Qualification | Passed 10th class examination |
| Minimum Age | 14 years as on first day of academic session. |
During the duration of this course, the students are imparted the knowledge on CNC Machining and employability skills related to the job role and trained on Skills related to CNC Machining. The students shall undertake live projects and are expected to engage in extracurricular activities so that his morale and confidence is built up. Practical skills are imparted on the Advanced CNC Machines and the theory related to this subject is taught in a way that the students are able to use their cognitive skills and use it while executing the task assigned to them.
The course is designed in such a way that the students can program and operate any Advanced CNC Turning Center, Vertical Machining Center with ATC and fourth axis. The students are given basic knowledge of TPM, and preventive maintenance. The students shall be able to perform self-inspection of the components made by them. The broad components covered under Professional Skill subject are as below:-
ADVANCED CNC MACHINING TECHNITION : Year wise Trade Overview
FIRST YEAR: Safety being the most important thing in all the industries now a day is covered in the first year to start with. The input in this trade is always the drawing, so the students are taught to read Industrial drawings, concept of GD & T and ISO Tolerances. The students are also introduced to latest trends and other advanced technologies. The students are oriented with the computer aided machining concept and given working knowledge of types of cutting tools & selection criteria. The students are also imparted the knowledge of materials used in industry and their properties & their impact on cutting tool life. The students are trained in use of different measuring instruments used in the industry and selection of appropriate measuring instrument based on the tolerance as per component drawing.
The practical training starts with the standard operating practices of the CNC Machines based on the operating manual like referencing, checking the condition of tools, spindle orientation, checking the daily check points etc. The students are taught the basic G-codes and M-codes used for programing the CNC Turning Center, making of program and running it in various modes and optimizing the program for idle movement for cycle time.
SECOND YEAR: In the second year, the students are taught the operation and programing of Vertical Machining Center with ATC and 4th axis.
The practical training starts with the standard operating practices of the VMC based on the operating manual like referencing, checking the condition of tools, spindle orientation, checking the daily check points etc. The students are taught the basic G-codes and M-codes used for programing the Vertical Machining Center, making of program and running it in various modes and optimizing the program for idle movement for cycle time.Alsooperatingandprogrammingof4&5axis machine, tool indexing, program creation & simulation. Preventive maintenance of machines & basic trouble shooting practices.
GENERAL
Directorate General of Training (DGT) under Ministry of Skill Development & Entrepreneurship offers range of vocational training courses catering to the need of different sectors of Labor market. The vocational training programs are running under aegis of Directorate General of Training (DGT). Craftsman Training Scheme (CTS) with variants and Apprenticeship Training Scheme (ATS) are two pioneer programs under DGT for propagating vocational training.
Advanced CNC Machining Technician trade under CTS is delivered nationwide through a network of ITIs. The course is of two years’ duration. It mainly consists of Domain area and Core area. The Domain area (Trade Theory & Practical) imparts professional skills and knowledge, while Core area (Employability Skills) imparts requisite core skill & knowledge and life skills. After passing out of the training program, the trainee is awarded National Trade Certificate (NTC) by DGT which is recognized worldwide.
Trainee broadly needs to demonstrate that they are able to:
- Read & interpret technical parameters/documentation, plan and organize work processes, identify necessary materials and tools;
- Perform tasks with due consideration to safety rules, accident prevention regulations and environmental protection stipulations;
- Apply professional knowledge, core skills & employability skills while performing the job, and repair & maintenance work.
- Self-certify the task / job with appropriate measuring tools depending on the tolerances / quality plan.
- Check the task/assembly as per drawing for functioning, identify and rectify errors in task/assembly.
- Document the technical parameters in tabulation sheet related to the task undertaken.
PROGRESSION PATHWAYS
- Can join industry as Technician and will progress further as Senior Technician, Supervisor and can rise up to the level of Manager.
- Can become Entrepreneur in the related field.
- Can take admission in diploma course in notified branches of Engineering by lateral entry.
- Can join Apprenticeship programme in different types of industries leading to National Apprenticeship certificate (NAC).
- Can join Crafts Instructor Training Scheme (CITS) in the trade for becoming instructor in ITIs.
- Can join Advanced Diploma (Vocational) courses under DGT as applicable.
COURSE STRUCTURE
Table below depicts the distribution of training hours across various course elements during a period of two years:
| S No. | Course Element | Notional Training Hours | |
|---|---|---|---|
| 1 st Year | 2nd Year | ||
| 1 | Professional Skill (Trade Practical) | 840 | 840 |
| 2 | Professional Knowledge (Trade Theory) | 240 | 300 |
| 3 | Employability Skills | 120 | 60 |
| Total | 1200 | 1200 | |
Every year 150 hours of mandatory OJT (On the Job Training) at nearby industry, wherever not available then group project is mandatory.
| 4 | On the Job Training (OJT)/ Group Project | 150 | 150 |
|---|
Trainees of one-year or two-year trade can also opt for optional courses of up to 240 hours in each year for 10th/ 12th class certificate along with ITI certification or add on short term courses.
LEARNING OUTCOMES
- Identify& comply with the safe working practices, environmental regulation and housekeeping. (NOS: CSC/N1335)
- Perform milling operations on simple components. (NOS: CSC/N0116)
- Perform Turning simple operations on simple parts. (NOS: CSC/N0115)
- Execute operations of unconventional machining processes. (NOS: CSC/N9408)
- Identify customer needs & Product specification. (NOS: CSC/N0115 )
- Draw and Interpret industrial engineering drawing & its requirements. (NOS: CSC/N0115)
- Construct the detail drawing of Machining stages. (NOS: CSC/N9401)
- Check the quality of surface finish adhering to Surface roughness factor. (NOS: CSC/N0115)
- Identify the measuring instruments and inspect the quality of final product. (NOS: CSC/N0115)
- Identify the cutting tools & apply work-piece holding techniques. (NOS: CSC/N0115 )
- Perform conventional and non-conventional (CNC Technology) manufacturing processes. (NOS: CSC/N0115)
- Apply M code & G Code used in CNC & VMC machines. (NOS: CSC/N0115,CSC/N0116)
- Perform Computer aided machining & Wire-frame Geometry Creation, Surface and Solid Modeling, Dimension, Importing and Exporting of files. (NOS: CSC/N0120,CSC/N0123)
- Verify Tool path Generation & Programming by using Computer Aided Manufacturing Software. (NOS: CSC/N0120,CSC/N0123)
- Explain the need of CNC turning, VMC machines & the machining component. (NOS: CSC/N0120,CSC/N0123)
- Explain the need of advanced CNC Turning Centre. (NOS: CSC/N0120)
- Perform operation on advanced CNC Turning Centre. (NOS: CSC/N0115)
- Identify CNC machines over travel limits & emergency stop, machine parts, various modes in CNC machines (Jog, MDI, Edit, Auto, Single Block, MPG) (NOS: CSC/N0120)
- Run the CNC program or subprogram. (NOS: CSC/N0120)
- Perform Programming of advanced CNC Turning Centre. (NOS: CSC/N0120)
- Create and edit the Linear interpolation, Rapid traverse program of CNC turning center. (NOS: CSC/N0120)
- Create and edit the Circular interpolation CW &CCW programs in turning center. (NOS: CSC/N0120)
- Demonstrate Tool nose radius compensation in CNC turning program. (NOS: CSC/N0120)
- Program Drilling cycles, boring cycle etc. in CNC turning center. (NOS: CSC/N0120)
- Create Absolute & Incremental program in CNC turning center. (NOS: CSC/N0120)
- Perform Importing & Exporting of CNC turning Program. (NOS: CSC/N0120)
- Perform preventive maintenance & basic trouble shooting of CNC turning center. (NOS: CSC/N0115)
- Read and apply engineering drawing for different application in the field of work. (NOS: CSC/N9401)
- Demonstrate basic mathematical concept and principles to perform practical operations. Understand and explain basic science in the field of study. (NOS: CSC/N9402)
- Operate advanced VMC machine. (NOS: CSC/N0116)
- Identify VMC machines over-travel limits & emergency stop, different machine parts, different mode used (Jog, MDI, Edit, Auto, Single Block, MPG). (NOS: CSC/N0123)
- Perform VMC movements by using G code & M code. (NOS: CSC/N0123)
- Create Programming of advanced VMC machine. (NOS: CSC/N0123)
- Perform Importing & Exporting of VMC Program. (NOS: CSC/N0123)
- Create Tool paths & Verify with the help of graphical icon on machine control panel. (NOS: CSC/N0123)
- Perform VMC preventive maintenance & basic trouble shooting. (NOS: CSC/N0116)
- Explain the need of 3, 4 & 5 Axis Machine. (NOS: ISC/N9416)
- Perform Operating & programming of 4 Axis Machine. (NOS: ISC/N9417)
- Perform Operating & programming 5 Axis Machine. (NOS: ISC/N9418)
- Demonstrate Programming & tool path simulation of 4 axes and 5 axes with the help of computer aided machining software. (NOS: ISC/N9419)
- Read and apply engineering drawing for different application in the field of work. (NOS: CSC/N9401)
- Demonstrate basic mathematical concept and principles to perform practical operations. Understand and explain basic science in the field of study. (NOS: CSC/N9402)
